High-resolution fingerprint access terminal with fast matching algorithm.
| Sensor Type | Capacitive fingerprint sensor |
| Resolution | 508 DPI |
| Matching Speed | <0.5 seconds |
| Fingerprint Capacity | 5,000 templates |
| FAR/FRR | FAR <0.0001% / FRR <0.01% |
| Log Capacity | 50,000 events |
| Communication | Wiegand 26/34, RS485, TCP/IP |
| Power Supply | 12V DC / 1A |
| Weather Rating | IP65 |
| Operating Temp | -20C to 55C |
| Dimensions | 120 x 80 x 35 mm |
The FP-Series delivers reliable fingerprint authentication for offices, factories, and secure facilities. Its capacitive sensor reads fingerprints in a single touch, with a fast matching algorithm that handles 5,000 templates with sub-second response times. The rugged housing is rated IP65 for indoor and outdoor mounting.
