ABS Case Access Controller
T12D Standalone RFID Access Control Keypad
Operating voltage: DC12V ±10%;
Operating current: <100 mA;
Temperature: -20 °C to 60 °C;
Button type:Physical Keypad
User capacity: 1,000 units;
Card type: ID card/125Khz
Card reading distance: 1–10 cm;
Dimensions: 120 × 78 × 22 mm
| Model | T12D |
| Power Supply | DC 12V ± 10% |
| User Capacity | 1000 Users |
| Keypad Type | Physical Keypad |
| Card Types | RFID/125Khz Frequency Card |
| Wiegand Interface | N/A / WG26 / WG34 Output(Optional) |
| Operating Temperature | -20°C to 60°C |
Keysecu T12D User Manual.pdfPDF document · 177.6 KB
Download
T12D Data Sheet.pdfPDF document · 367.0 KB
Download
2 files are available for this product.
