Feature:

1.Has two-way output relays. Two outputs of them are unlimited when the corresponding loop is permanently covered, while the others are multi-mode that can be set by users. The direction detecting Function can be used to statistics the vehicle flux.
2. The principle is based on a change in the inductance within? the loop which is caused by the metallic components of passing vehicles.
3. The changes are picked up and evaluated by a microprocessor. Ease of use thanks to automatic calibration when the operating voltage is applied.



Parameter
Supply voltage
220V, 110V, 24V, 12V
Supply voltage DC
24V, 12V
Power Consumption:
4.5VA
Storage temperature
-40°C to +85°C
Operating temperature
-20°C to +70°C
Storage temperature
40°C to +85°C
Frequency range:
20 kHz to 170 kHz
Reaction time
100ms
Signal holding time
Unlimited
Sensitivity
Adjustable in 3 increments
Loop inductance
Ideal:80μH to 300μH (incl. conn. wiring); max:50μH to 500μH
Loop connection
<5m optimal
Loop connection wiring
Maximum length 200 meters, Twisted at least 20 times per meter
